Reelmaster® 3555/3575 Mower
Overview
The Reelmaster 3555-D and 3575-D (5 and 7 inch reel) reel mowers provide productivity, efficiency, and simplicity. The 100 inch width of cut and lighter cut makes it perfect for sports fields. These mowers were designed to be over 20% lighter and much more compact than traditional Toro reel mowers. You get the performance you come to expect from Toro in a size that is not only highly maneuverable, but is also engineered to decrease turf compaction.
Configuration Options:
- Reelmaster 3555-D 5″ Cutting Reels
- Reelmaster 3575-D 7″ Cutting Reels
Features
Engine Efficiency
Powered by a 24.8 hp (18.5 kW) Kubota diesel engine. The Reelmaster 3555-D and 3575-D provides plenty of power to climb hills, even while operating groomers and rear roller brushes, yet it uses less fuel per acre than a traditional fairway mower.Quiet Operation
The Reelmaster 3555-D & 3575-D has a quiet, low noise design with only 84 dB(A) at the operator’s ear & 73 dB(A) at a 25-foot drive by.Superior Traction
The innovative Series/Parallel 3-wheel drive system provides power to at least two wheels at all times. The result is impressive traction in hilly and wet conditions, and minimal wheel slip so it’s gentle on the turf.Three Wheel Design
The three wheel design is highly maneuverable which maximizes productivity. Smooth, turf-friendly tires significantly decrease potential for turf tear in tight turns. The 100 inch (2.5 m) cutting width and up to 7 mph (11.3 km/hr) mowing speed make the 3555-D and 3575-D fast and effective.Simplicity
The Reelmaster 3555-D and 3575-D utilize a common platform with other popular Toro mowers, which reduces operator training time and increases productivity.Lightweight Design
With a weight that is 20 percent lighter than a comparably equipped Toro 4-wheel drive reel machine, the Reelmaster 3555-D and 3575-D provides the ideal combination of turf friendliness and productive performance.EdgeSeries™ Reels
Dual Precision Adjustment (DPA) cutting units – featuring Toro’s EdgeSeries™ reels combine to deliver a consistent, high quality cut and superior after cut appearance, while reducing maintenance with improved reel edge retention.
Specifications
- Engine
24.8 hp (18.5 kw) Kubota® 3-cylinder, liquid-cooled diesel engine - Mowing Speed
0 – 7 mph (0-11.3 km/h) with mow limiter
- Transport Speed
0 – 10 mph (0 – 16.1 km/h) forward transport; 0 – 3.5 mph (0 – 5.6 km/h) reverse.
- Backlapping
Standard on-board - Cutting Units
Dual Precision Adjustment (DPA) Cutting Units
- Height of Cut
0.25” – 1.5” (6.4-38.1 mm) - Reel Diameter
5 in (12.7 cm)
- Number of Blades
8 and 11 blade - Reel Drive
Hydraulic
- Reel Length
22 in (56 cm) - Traction Drive
Series/Parallel full time 3-wheel drive
